PMX Series Low Clearance Hydraulic Torque Wrench
PMX Series Low Clearance Hydraulic Torque Wrench
1.Constructed from high strength alloy with light weight, high torque ratio.
Hydraulic Torque Wrenches
Product categoryHydraulic Torque Wrenches
Model rangePMX-2, PMX-4, PMX-8, PMX- 14, PMX-30
Range of Hex A/F(in)3/4~2-3/8 – 3- 1/2~5-3/4
Range of Hex A/F(mm)19-60 – 90- 155
Overview
1.Constructed from high strength alloy with light weight, high torque ratio. 2.Slim body design fits for various tight spaces. 3.Anti-corrosive treated surface applicable for harsh environment . 4.The wrench head is equipped with copper sleeve which makes it more wear-resistant, non-stuck and high torque precision. 5.Power head connects to the wrench head through a hook, no risk of dislodging the wrench head. 6.Solid single link pin makes symmetrical load of both side plates.
Features
- Constructed from high strength alloy with light weight, high torque ratio.
- Slim body design fits for various tight spaces.
- Anti-corrosive treated surface applicable for harsh environment .
- The wrench head is equipped with copper sleeve which makes it more wear-resistant, non-stuck and high torque precision.
- Power head connects to the wrench head through a hook, no risk of dislodging the wrench head.
- Solid single link pin makes symmetrical load of both side plates.
Specifications
Product categoryHydraulic Torque Wrenches
Model rangePMX-2, PMX-4, PMX-8, PMX- 14, PMX-30
Range of Hex A/F(in)3/4~2-3/8 – 3- 1/2~5-3/4
Range of Hex A/F(mm)19-60 – 90- 155
Min.Torque(Nm)228 – 4200
Max.Torque(Nm)2287 – 42005
Power head weight(Kg)0.9 – 10.4
Hex Link Weight(Kg)1.5 – 20.5
Output accuracy±3%
L(mm)194 – 478
Technical Data
Technical table 1
Model | Range of Hex A/F(in) | Range of Hex A/F(mm) | Min.Torque(Nm) | Max.Torque(Nm) | Power head weight(Kg) | Hex Link Weight(Kg) | Output accuracy | Repeat Accuracy
PMX-2 | 3/4~2-3/8 | 19-60 | 228 | 2287 | 0.9 | 1.5 | ±3% | 2%
PMX-4 | 1-7/16~3- 1/8 | 36-80 | 522 | 5226 | 1.7 | 3.4 | ±3% | 2%
PMX-8 | 1- 13/16~3- 11/16 | 46- 105 | 1104 | 11049 | 3 | 6.3 | ±3% | 2%
PMX- 14 | 2-3/8~4-5/8 | 60- 120 | 1816 | 18165 | 4.6 | 11.4 | ±3% | 2%
PMX-30 | 3- 1/2~5-3/4 | 90- 155 | 4200 | 42005 | 10.4 | 20.5 | ±3% | 2%
Technical table 2
Model | L(mm) | A1(mm) | A2(mm) | W1(mm) | W2(mm) | C(mm)
PMX-2 | 194 | 136 | 103 | 32 | 50 | 9.8- 12.6
PMX-4 | 258 | 172 | 137 | 42 | 66 | 12.5- 13. 1
PMX-8 | 312 | 200 | 170 | 53 | 83 | 16- 16.7
PMX- 14 | 373 | 242 | 205 | 63 | 99 | 17.6- 18.9
PMX-30 | 478 | 312 | 272 | 83 | 132 | 24.4-26.2
Technical table 3
PMX-2 | PMX-4 | PMX-8 | PMX-14 | PMX-30
Model | Hex Size A/F(mm) | Model | Hex Size A/F(mm) | Model | Hex Size A/F(mm) | Model | Hex Size A/F(mm) | Model | Hex Size A/F(mm)
PMXL2- 19 | 19 | PMXL4-36 | 36 | PMXL8-46 | 46 | PMXL14-60 | 60 | PMXL30-90 | 90
PMXL2-22 | 22 | PMXL4-41 | 41 | PMXL8-50 | 50 | PMXL14-65 | 65 | PMXL30-95 | 95
PMXL2-24 | 24 | PMXL4-46 | 46 | PMXL8-55 | 55 | PMXL14-70 | 70 | PMXL30- 100 | 100
PMXL2-27 | 27 | PMXL4-50 | 50 | PMXL8-60 | 60 | PMXL14-75 | 75 | PMXL30- 105 | 105
PMXL2-30 | 30 | PMXL4-55 | 55 | PMXL8-65 | 65 | PMXL14-80 | 80 | PMXL30- 110 | 110
PMXL2-32 | 32 | PMXL4-60 | 60 | PMXL8-70 | 70 | PMXL14-85 | 85 | PMXL30- 115 | 115
PMXL2-36 | 36 | PMXL4-65 | 65 | PMXL8-75 | 75 | PMXL14-90 | 90 | PMXL30- 120 | 120
PMXL2-41 | 41 | PMXL4-70 | 70 | PMXL8-80 | 80 | PMXL14-95 | 95 | PMXL30- 130 | 130
PMXL2-46 | 46 | PMXL4-75 | 75 | PMXL8-85 | 85 | PMXL14- 100 | 100 | PMXL30- 145 | 145
PMXL2-50 | 50 | PMXL4-80 | 80 | PMXL8-90 | 90 | PMXL14- 105 | 105 | PMXL30- 150 | 150
PMXL2-55 | 55 | PMXL8-95 | 95 | PMXL14- 110 | 110 | PMXL30- 155 | 155
PMXL2-60 | 60 | PMXL8- 100 | 100 | PMXL14- 115 | 115
PMXL8- 105 | 105 | PMXL14- 120 | 120
Technical table 4
PMX-2 | PMX-4 | PMX-8 | PMX-14 | PMX-30
Model | Hex Size A/F(in) | Model | Hex Size A/F(in) | Model | Hex Size A/F(in) | Model | Hex Size A/F(in) | Model | Hex Size A/F(in)
PMXL2-3/4 | 3/4 | PMXL4- -7/16 | 1-7/16 | PMXL8-1- 3/16 | 1- 13/16 | PMXL14-2-3/8 | 2-3/8 | PMXL30-3- 1/2 | 3- 1/2
PMXL2-7/8 | 7/8 | PMXL4- 1-5/8 | 1-5/8 | PMXL8-2 | 2 | PMXL14-2-9/16 | 2-9/16 | PMXL30-3- 11/16 | 3- 11/16
PMXL2-1- 1/16 | 1- 1/16 | PMXL4-1- 3/16 | 1- 13/16 | PMXL8-2-3/16 | 2-3/16 | PMXL14-2-3/4 | 2-3/4 | PMXL30-3-7/8 | 3-7/8
PMXL2-1-3/16 | 1-3/16 | PMXL4-2 | 2 | PMXL8-2-3/8 | 2-3/8 | PMXL14-2-15/16 | 2- 15/16 | PMXL30-4-1/8 | 4- 1/8
PMXL2- 1- 1/4 | 1- 1/4 | PMXL4-2-3/16 | 2-3/16 | PMXL8-2-9/16 | 2-9/16 | PMXL14-3- 1/8 | 3- 1/8 | PMXL30-4- 1/4 | 4- 1/4
PMXL2-1-7/16 | 1-7/16 | PMXL4-2-3/8 | 2-3/8 | PMXL8-2-3/4 | 2-3/4 | PMXL14-3- 1/2 | 3- 1/2 | PMXL30-4-5/8 | 4-5/8
PMXL2- 1-5/8 | 1-5/8 | PMXL4-2-9/16 | 2-9/16 | PMXL8-2-5/16 | 2- 15/16 | PMXL14-3-11/16 | 3- 11/16 | PMXL30-5 | 5
PMXL2-1- 3/16 | 1- 13/16 | PMXL4-2-3/4 | 2-3/4 | PMXL8-3- 1/8 | 3- 1/8 | PMXL14-3-7/8 | 3-7/8 | PMXL30-5-3/8 | 5-3/8
PMXL2-2 | 2 | PMXL4-2- 15/16 | 2- 15/16 | PMXL8-3- 1/2 | 3- 1/2 | PMXL14-4- 1/8 | 4- 1/8 | PMXL30-5-3/4 | 5-3/4
PMXL2-2-3/16 | 2-3/16 | PMXL4-3- 1/8 | 3- 1/8 | PMXL8-3- 11/16 | 3- 11/16 | PMXL14-4- 1/4 | 4- 1/4
PMXL2-2-3/8 | 2-3/8 | PMXL14-4-5/8 | 4-5/8
