Features

• Double closed-loop controlled to achieve pressure and torque controlled precisely, pressure control accuracy of 1%, torque control accuracy of 2%
• Double working mode, can be worked with hydraulic wrench or tensioner intelligently, run up to 4 tensioner simultaneously
• Digital parameter setting. The hydraulic wrench and tensioner model, parameters, the target pressure and torque can be preset
• Constantly collect hydraulic pressure and torque data. Record working data such as load and torque for each bolt
• Can be used as a single pump, but also can be connected with robot integrated system to achieve automatic bolt tightening operation
• Can be achieve batch recording and uploading of work data, long distance fault diagnosis and maintenance with smart hand held terminals
• Intelligent control servo motor speed, energy-saving and noise reduction, reduce wear and tear, extend product life
• Automatic fault detection and alarm, automatic oil level detection and alarm

Specifications

Technical Data

Technical table 1
Model | ReservoirCapacity(L) | MotorSize(KW) | Supply | Output Flow(L/min) | Max. WorkingPressure(MPa) | Size(mm)A× B×C | Control Line(m) | Weight(kg)
PES01A | 20 | 1.5 | 220V/50Hz/Single Phase | 1.1@70MPa | 70 | 700×430×670 | 6 | 58
