Electric-Hydraulic Pump

Electric-Hydraulic Pump — 1. Advanced 3 stage flow design

Hydraulic Pumps

Product categoryHydraulic Pumps

Model rangePA1, PA2, PA3, PA4

Reservoir Capacity(L)7.6 – 4

Motor Size(KW)1.1 – /

Ask an Engineer Download Datasheet

Overview

1. Advanced 3 stage flow design 2. Powerful startup,can be started at any time under pressure 3. High-power brushless electric motor, maintenance-free 4. Small and lightweight, easy to carry 5. Capable of multi-synchronous operation 6. Large flow with high speed 7. One pair of quick connectors is available for standard configuration. Please specify in the order for two or four pairs of quick connectors 8. Solid aluminum alloy electrical box

Features

Advanced 3 stage flow design
Powerful startup,can be started at any time under pressure
High-power brushless electric motor, maintenance-free
Small and lightweight, easy to carry
Capable of multi-synchronous operation
Large flow with high speed
One pair of quick connectors is available for standard configuration. Please specify in the order for two or four pairs of quick connectors
Solid aluminum alloy electrical box

Specifications

Product categoryHydraulic Pumps

Model rangePA1, PA2, PA3, PA4

Reservoir Capacity(L)7.6 – 4

Motor Size(KW)1.1 – /

Supply220V/50Hz/ single-phase

Output Flow(L/min)8.0@0-6.5MPa, 1.8@6.5-32MPa, 0.85@32-70MPa

Max.Pressure (MPa)70

Size(mm) A× B×C375 ×300 ×410 × 155

Control Line (m)6

Technical Data

Technical table 1
Model | Reservoir Capacity(L) | Motor Size(KW) | Supply | Output Flow(L/min) | Max.Pressure (MPa) | Size(mm) A× B×C | Control Line (m) | Weight(kg) | Port No. | Auto heat
PA1 | 7.6 | 1.1 | 220V/50Hz/ single-phase | 8.0@0-6.5MPa, 1.8@6.5-32MPa, 0.85@32-70MPa | 70 | 375 ×300 ×410 × 155 | 6 | 25 | 2 | /
PA2 | 2 | yes
PA3 | 4 | /
PA4 | 4 | yes
